EnCal 3000 Hardware Manual 73022344 o 50
Figure 6.4: Plan view with dimensions (without couplings and connections)
6.3.2 Place of use and installation site (protection from environmental influences, etc.)
CAUTION
Obey the explosion-protection rules at all times when working with tools
or on items in hazardous zones
The EnCal 3000 must be installed as close as possible to the
process gas sampling point to avoid having long supply lines and to
ensure that you obtain current measurements.
