Honeywell ENCAL 3000 User Manual

HARDWARE INSTALLATIO
N
EnCal 3000 Hardware Manual 73022344 o 48
There must be a minimum gap of 700 m above the base of the device and 100 mm in
front of the gas connections or a radius of 225 mm around the centre of the cover.
Select an installation height between 1.00 m and 1.50 m above the floor
which is suitable for maintenance work.
We recommend that you use larger gaps to make installation and maintenance work
easier. The following sketch shows these requirements.
Figure 6.2: Minimum installation gaps
