EnCal 3000 Hardware Manual 73022344 o 9
Symbol on device
Symbol on deviceSymbol on device
Symbol on device
Meaning
MeaningMeaning
Meaning
Device symbol
The symbol on the device is a reminder to comply with all the
instructions and important information in the manual (in
this document). The appropriate parts are marked with the
other symbols in this table.
Device symbol
The symbol on the device is a reminder to comply with the
WEEE directive of the EU. In the interest of our environment
the WEEE directive did not allow to dispose the device with
household waste within the EU!
Device symbol
This symbol on the device means that the power supply is
24 V DC.
Device symbol
This symbol on the device designates the equipotential
bonding connection (PA) or the terminal for the electrical
connection to the equipotential bonding system and earth.
Device symbol
This symbol on the device designates the connection for the
functional earth (FE).
Denotes tips and recommendations which are interesting
and useful for a certain topic, but which have no bearing on
safety.
