FMC2000 User’s Guide
4.1 Rear View and Side View Of Enclosure
4.2 Mounting the FMC2000
The FMC2000 is designed to be wall-mounted and has four
keyhole-type captures on its back, allowing for attachment to four
mating studs extending from a bracket that is designed to be pre-
installed on a wall.
Follow these steps:
1. Install the mounting plate first. Mark the locations for the six
screws.
