A Zone Expander
B ControlPanel
C 4G/LTE Module
D Door tamper switch
E Optional: off-wall tamper switch (not included)
F AC power adapter
G Earth lead
The image below shows a cabinet with a Remote Power Supply (H), a Zone
Expander (I) on top, and a Door ControlModule (C) to the side.
H Remote Power Supply
I Zone Expander
J Door ControlModule
26 800-23044 Rev. A draft_11
Installation and Setup Guide Honeywell MAXPRO Intrusion MPIP2000U/3000U Series
