Honeywell MAXPRO Intrusion MPIP2000U/3000U Series Installation and Setup Guide
800-23044 Rev. A draft_11 45
State at input terminals Message to the system
Short circuit Alarm
X ohms (EOLR value) Ready
Open circuit Trouble
3.9 Wiring Alarm Sounders
3.9.1 Overview
The following alarm sounder outputs are available on the control panel:
l Two outputs, BELL 1 and BELL 2, for 2-wire externalsirens. For details, see
Installing Supervised External Sirens (2-Wire Sirens BELL1/BELL2) on page45.
l An output to a self-activating bell (SAB). For details, see Installing a Self-
Activating Bell (SAB) on page47.
3.9.2 Installing Supervised External Sirens (2-Wire Sirens BELL1/BELL2)
3.9.2.1 Features
The control panel provides a bell output, also called alarm output, for operating
fire and burglary alarm notification appliances (E on page34). The output is
rated 12VDC, 1.8A max. (each).
The output has the following options (MAXPROCloud):
l Selectable for supervision.
l Selectable for confirmation of arming ding.
l Selectable for a timeout of 2–30minutes.
UL
Burglary bell circuits must be programmed for a timeout of 16
minutes or longer.
UL
This control panel complies with National Fire Protection Association
(NFPA) requirements for temporal3pulse sounding of fire
notification appliances, and for temporal 4pulse sounding for CO
alarm signalling (on keypad only).

Honeywell MAXPRO MPIP2000U Series Specifications

General

Brand	Honeywell
Model	MAXPRO MPIP2000U Series
Category	Security System
Language	English
