You can bypass the tamper switches by fitting a jumper on the tamper inputs
on the control panel.
Caution!
Bypassing tamper inputs may invalidate compliance with local
regulations.
UL
The cabinet wall tamper is optional for UL/ULC installations.
3.7 Network Connection (Ethernet)
3.7.1 Connecting to the Network
The Ethernet connection provides the main connection to internet for alarm
signalling to the central monitoring station and communication with MAXPRO
Cloud.
Connect the main board (M on page34) to the network that provides the
internet connection using a standard Ethernet cable. Clip both ferrite beads
over the cable. Position them as close as possible to the Ethernet connector on
the control panel.
l The amber LED is illuminated when the network connection is working.
l The green LED flashes when the system is sending or receiving data over
the network.
Upon first start-up, MAXPRO Cloud will automatically try and connect to the
control panel. By default, the system uses dynamic IP addressing (DHCP). If
connection should fail, you can edit the settings using the keypad and set up
the IP network manually. For details, see Connecting to MAXPRO Cloud on
page119. You can view the network settings in MAXPROCloud.
3.7.2 Securing the Network
Make sure that the routers and firewalls in the network are set up correctly:
network address translation (port forwarding), firewall settings, etc. If not, the
control panel will not be able to send alarm and other information to MAXPRO
Cloud. The table below lists the port numbers and services that are required for
communication:
Port No. Protocol Function
53 UDP DNS server
38 800-23044 Rev. A draft_11
Installation and Setup Guide Honeywell MAXPRO Intrusion MPIP2000U/3000U Series
