2. Secure the control panel to the mounting rails in the cabinet using the
4screws supplied with the control panel.
3.3.3 Options
You can mount a Zone Expander or Relay Module on top of the main circuit
board holder. For details, see Cabinet Mounting with Control Panel or Remote
Power Supply on page96.
3.4 Overview of Control Panel Connectors
Below is a general overview of the connectors and terminals on the control
panel. Detailed instructions are in the sections and chapters further below.
The image below is for the MPIP3000 series. Not all connectors and terminals
may be available on the MPIP2000 series.
UL
You must run all cabling to the control panel in conduit.
