Honeywell MAXPRO MPIP2000U Series - 3.10 Wiring Outputs

The default settings in MAXPRO Cloud are suitable for this SAB configuration:
Trigger Output1 = Exterior Siren; and Trigger Output2 = Strobe. If you
have wired up the SAB as shown, you do not need to change the settings.
3.10 Wiring Outputs
The control panel offers the following outputs:
l Four programmable low-voltage trigger outputs (P on page34): for arming
LEDs, smoke detector power reset, etc.
Wire the AUX1 +12V to the output device, and then use one of the trigger
terminals 1to4 to switch to ground. The outputs will switch to ground when
activated.
Max. current is 50mA for each trigger.
For outputs that require a known state (logical 0/1), you can customise the
outputs to use a pull-up resistor by fitting jumpers on the outputs.
l Two relay outputs, 28VDC, 2.8A max., resistive loads (N/O on page34).
Wire the relays between the common C terminal and the normal closedNC
or normal open NO terminals.
