PAGINA - 10 Installation and programming manual AM-1224
NOTIFIER ITALIA Doc. M-124.1-AM1224-ENG Rev A.1 AM-1224_manu
1
1
6
6
O
O
u
u
t
t
p
p
u
u
t
t
s
s
o
o
p
p
t
t
i
i
o
o
n
n
a
a
l
l
c
c
a
a
r
r
d
d
CN3 terminals
CN3 Description Jumper Reference to
Program CBE
Note
1 Relay 1 - Com.
2 Relay 1 - NO-NC
J2 U01
3 Relay 2 - Com.
4 Relay 2 - NO-NC
J4 U02
5 Relay 3 - Com.
6 Relay 3 NO-NC
J6 U03
7 Relay 4 - Com.
8 Relay 4 - NO-NC
J8 U04
Max 2A 30Vcc resistive load,
Contact NO-NC selectable by
jumper
9 Output OC1 U09
10 Output OC 2 U10
11 Output OC 3 U11
12 Output OC 4 U12
Open collector
Max Current 30mA
13 Relay 5 Com.
14 Relay 5 NO-NC
J1 U05
15 Relay 6 Com.
16 Relay 6 NO-NC
J3 U06
17 Relay 7 Com.
18 Relay 7 NO-NC
J5 U07
19 Relay 8 Com.
20 Relay 8 NA-NC
J7 U08
Max 2A 30Vcc resistive load,
Contact NO-NC selectable by
jumper
21 Output OC 5 U13
22 Output OC6 U14
23 Output OC7 U15
24 Output OC8 U16
Open collector
Max Current 30 mA
CN3
terminal
block
J SERIES:
contact relay selection Jumper
Default: N.O.
Base board
terminal block
