FireWarden 100-2/E — P/N 52778:A 11/04/2005 47

Master Programming Level Programming

If the selected address has been added to programming, device summary screens will be displayed.

These screens allow the programmer to view all device settings at a single glance. Pressing the left

or right arrow keys will allow the programmer to rapidly view the devices at the previous or next

address (if installed).

If a detector (such as a photoelectric detector) with the selected address is not physically installed

on the SLC or has a communication fault but the address is programmed in the system, the

following screen will be displayed:

If the selected address has been added to programming and a detector (such as a photoelectric

detector) with the selected address is physically installed on the SLC and is communicating with

the control panel, the following will be displayed:

To change the programming for the displayed detector, press the keyboard ‘down’ arrow key to

view the Edit Detector screens.

In the preceding example:

• Normal - indicates that the detector with the selected address is physically installed on the

SLC and communicating with the control panel (enabled)

• <ADJ><NOUN> - represents the adjective and noun, which have been programmed,

describing the location of the displayed device

• ZNNN - represents the first of five possible software zones that the detector is assigned to

(NNN = the three digit zone number from 000 - 099)

• V or * - indicates whether or not alarm verification is enabled (V = alarm verification

enabled and * = alarm verification disabled)

• 1D017 - represents the Loop, Device type and Device address (1 = SLC Loop, D=Detector

and 017 = Detector Address 017)

TROUBL SMOKE(PHOTO)

ZNNN

* 1D017

Edit Detector Screen #1

NORMAL SMOKE (PHOTO)

ZNNN

V 1D017

Edit Detector Screen #1
