FireWarden 100-2/E — P/N 52778:A 11/04/2005 97
Master Programming Level Programming
Terminal 1 and Terminal 2
Service Terminal #1 is generally designated as the FACP primary phone line used for receiving
phone calls from the service terminal (PC) being used for remote programming. Service Terminal
2 is referred to as the secondary phone line. Pressing 2 for Terminal 1 or 3 for Terminal 2 while
viewing Service Terminal Screen #1 will display the following screen:
Phone Number (Service Terminal)
The Service Terminal Phone Number will be used by the control panel to contact the service
terminal. Pressing 1 while viewing the Service Terminal # Screen will cause the following screen
to be displayed:
A flashing cursor will appear in the lower left corner. Enter the phone number for the service
terminal by keying in the first digit, pressing the left arrow key and entering the second digit.
Continue this process until all desired numbers have been entered (maximum of 20 characters).
Press the Enter key to store the phone number in memory and return the display to the Service
Terminal # Screen.
Valid entries are 0 - 9 and A - F with the numeric digits as dialed numbers and letters representing
the following functions:
• A = * on a Touchtone phone keypad
• B = # on a Touchtone phone keypad
• C = look for secondary dial tone for up to two seconds (then dial anyway)
• D = three second pause
• E = five second pause
• F = end of phone number (F is automatically entered for unused entry positions)
SERVICE TERMINAL
1=PANEL ID
2=TERMINAL 1
3=TERMINAL 2
Service Terminal Screen #1
SERVICE TERMINAL #
1=PHONE NUMBER
Service Terminal # Screen
PHONE NUMBER
20 NUMBERS MAXIMUM
Printer-PC Screen
To Next Page
