Notifier SLC Wiring Manual — P/N 51253:U9 12/3/2021 15
Devices Introduction
1.6.8 Intelligent Detectors
FSP-951-SELFT Self-test photo detector; FlashScan; N16 only; UL applications only.
FSP-951T-SELFT Self-test photo/heat detector; FlashScan; N16 only; UL applications only.
FST-951-SELFT Self-test heat detector; FlashScan; N16 only; UL applications only.
FCO-951, FCO-951-IV Addressable intelligent multi-criteria smoke sensors: photo, carbon monoxide (CO), 135°F (57.2°C)
fixed-temperature heat detector, and infra-red (IR). Transmits an alarm signal due to heat (135°F/57.2°C) per UL 521. (Main model
is white; -IV is ivory.)
FPC-951 Multi-Criteria Photoelectric and CO Sensor. (White)
FPTI-951, FPTI-951-IV Multi-Criteria Photoelectric, Thermal and Infra-Red Sensor. (Main model is white; -IV is ivory.)
FSCO-951 Intelligent Carbon Monoxide Sensor. (White)
FS-OSI-RI Addressable, intelligent, single-ended beam smoke detector.
FSV-951, FSV-951-IV Intelligent High-sensitivity Photoelectric Smoke Sensors, FlashScan. (-IV versions support FlashScan and
CLIP.)
FSV-951R, FSV-951R-IV Intelligent High-sensitivity Photoelectric Smoke Sensors, Retrofit (Backwards compatible for use with
older panels). FlashScan. (-IV versions support FlashScan and CLIP.)
VESDA-E series aspiration smoke detectors provide fire protection for NFS-320, NFS-320SYS, NFS2-640, and NFS2-3030 in
FlashScan mode. Address using VSC software.
VESDA-E, UL 268 6th edition/ULC:
VEP-A00-P-NTF Addressable VESDA-E VEP with LEDs, UL 268 6th edition/ULC
VEP-A10-P-NTF Addressable VESDA-E VEP with 3.5" Display, UL 268 6th edition/ULC
VEP-A00-1P-NTF Addressable VESDA-E VEP 1 Pipe with LEDs, UL 268 6th edition/ULC
VEU-A00-NTF Addressable VESDA-E VEU with LEDs, UL 268 6th edition/ULC
VEU-A10-NTF Addressable VESDA-E VEU with 3.5" Display, UL 268 6th edition/ULC
VEA-040-A00-NTF Addressable VESDA-E VEA-40 point with LEDs, UL 268 6th edition/ULC
VEA-040-A10-NTF Addressable VESDA-E VEA-40 point with 3.5" Display, UL 268 6th edition/ULC
VESDA-E, UL 268 7th edition:
VEP-A00-P-NTF-UL Addressable VESDA-E VEP with LEDs, UL 268 7th edition
VEP-A10-P-NTF-UL Addressable VESDA-E VEP with 3.5" Display, UL 268 7th edition
VEP-A00-1P-NTF-UL Addressable VESDA-E VEP 1 Pipe with LEDs, UL 268 7th edition
VEU-A00-NTF-UL Addressable VESDA-E VEU with LEDs, UL 268 7th edition
VEU-A10-NTF-UL Addressable VESDA-E VEU with 3.5" Display, UL 268 7th edition
VEA-040-A00-NTF-UL Addressable VESDA-E VEA-40 point with LEDs, UL 268 7th edition
VEA-040-A10-NTF-UL Addressable VESDA-E VEA-40 point with 3.5" Display, UL 268 7th edition
VES-A00-P-NTF-UL Addressable VESDA-E VES scanning detector with LEDs, FlashScan, UL 268 7th edition
VES-A10-P-NTF-UL Addressable VESDA-E VES scanning detector with 3.5" Display, FlashScan, UL 268 7th edition
FCO-851 IntelliQuad PLUS Intelligent Photoelectric Multi-Criteria Smoke/CO (Carbon Monoxide) detector. Plug-in type smoke sensor
that is a photoelectric sensing chamber combined with Carbon Monoxide (CO), thermal, and infra-red (IR) sensors to help reduce false
alarms. For CO, the detectors electromechanical sensing cell creates a separate indication of for life safety CO detection. The FCO-851
adds thermal sensors that will alarm at a fixed temperature of 135° F (57.2° C) and alarm sensitivity options with built-in alarm and pre-
alarm time delay. FlashScan mode only.
FSB-200S Addressable, intelligent, single-ended beam smoke detector with built-in sensitivity testing. The FSB-200 is the same except
that it does not provide sensitivity testing. Both models support FlashScan and CLIP mode.
FAPT-851 (Acclimate
®
Plus™) Addressable, intelligent detector that combines a photoelectric sensing chamber and fixed temperature
heat detection (135°F / 57.2°C). FlashScan- and CLIP-mode capable. (An earlier version named FAPT-751 was also FlashScan capable.
The model named IPX-751 was discontinued as of December 1, 2001.)
FSC-851 IntelliQuad Intelligent Photoelectric Multi-Criteria Smoke Sensor. Plug-in type smoke sensor that is a photoelectric sensing
chamber combined with Carbon Monoxide (CO), thermal, and infra-red (IR) sensors to help reduce false alarms. The FSC-851 adds
thermal sensors that will alarm at a fixed temperature of 135° F (57.2° C) and alarm sensitivity options with built-in alarm and pre-alarm
time delay. Notifier panels offer different feature sets across different models. Certain features of the FSC-851 may not be available on
some panels. The FSC-851 supports both FlashScan and CLIP modes. Read Status limitations may apply in CLIP mode.
FSI-851 Addressable, intelligent smoke detector that incorporates an ionization sensing chamber. Designed to provide open area protec-
tion. FlashScan- and CLIP-mode capable. (An earlier model named FSI-751 (discontinued) was also FlashScan- and CLIP-mode capa-
ble. Earlier models named CPX-751 and CPX-551 were CLIP mode only.)
NOTE:
The alarm and threshold limits determined by the control unit interconnected to detectors that employ a special application
mode/configuration are designed and shipped from the factory with the detector sensitivity setting set to an acceptable open area protection
sensitivity being the default mode of operation.
The special application mode/configuration shall not be activated at the control unit without a deliberate action by the user to initiate the
special application mode through an alternate detector sensitivity selection setting.
Additionally, the extended label should be modified at this address to include the phrase ‘SPECIAL APPLICATIONS’ or ‘SPECIAL APPS’ for
compliance with UL 864 requirements. Refer to the FACP programming/installation instructions for further instructions on altering extended
labels.
