80 Notifier SLC Wiring Manual — P/N 51253:U9 12/3/2021
Canadian Versions of SLC Devices
VES-A00-P-NTF-UL — Addressable VESDA-E VES scanning detector with LEDs, FlashScan, UL
268 7th edition
VES-A10-P-NTF-UL — Addressable VESDA-E VES scanning detector with 3.5" Display, FlashScan,
UL 268 7th edition
Bases
B300-6 B3006A Standard U.S. Low-Profile base (6", 15.24 cm). White.
B300-6-IV B3006A-IV Standard U.S. Low-Profile base (6", 15.24 cm). Ivory.
B210LP B210LPA Standard U.S. Low-Profile base (6", 15.24 cm). Legacy ivory; replaced by
B300-6/-IV.
B501 (before March 2018) B501A (before March 2018)s Legacy ivory; replaced by B501-WHITE/-IV/-BL.
B501-WHITE B501-WHITE
(replaces B501A)
Standard European flangeless base (4", 10.16 cm). White.
B501-IV B501-IV Ivory version of B501-WHITE.
B501-BL B501-BL Black version of B501-WHITE.
B710LP B710LPA Standard U.S. Low-Profile base (6", 15.24 cm). Discontinued.
B501BH, B501BHT B501BHA, B501BHTA Sounder base, includes B501/A Sounder base with temporal sounder (UL
8th Edition) Discontinued.
B501BH-2, B501BHT-2 N/A Sounder base, includes B501/A Sounder base with temporal sounder (UL
9th Edition) Discontinued.
B224RB-WH, B224RB-IV B224RBA-WH, B224RBA-IV Low Profile Intelligent relay base. Replaces legacy ivory B224RB(A).
B224BI-WH, B224BI-IV B224BIA-WH, B224BIA-IV Low Profile Intelligent isolator base. Replaces legacy ivory B224BI(A).
B710HD B710HDA Base for a hostile environment detector.Legacy ivory.
B200S-WH, B200S-IV B200SA-WH, B200SA-IV,
B200SCOA-WH,
B200SCOA-IV
Addressable sounder base. Replaces legacy ivory B200S(A), and legacy
ivory B200SCOA.
B200SCOA-WH/IV provides
CO detector markings in English/French, for
Canadian applications only.
B200SR-WH, B200SR-IV B200SRA-WH, B200SRA-IV Sounder base. Replaces legacy ivory B200SR(A).
Note: Because low-frequency bases are designed for a UL requirement, there is no ULC-listed version of B200S-LF-WH/B200S-LF-IV or
for B200SR-LF-WH/B200SR-LF-IV.
Monitor and Zone Interface Modules
FMM-1 FMM-1A Used for normally open contact alarm initiating devices, such as manual pull
stations, four-wire smoke detectors, heat detectors, waterflow, and
supervisory devices.
FZM-1 FZM-1A Used to interface with two-wire smoke detectors in addition to normally open
contacts.
FDM-1 FDM-1A Provides two independent 2-wire Initiating Device Circuits (IDCs) at two
separate, consecutive addresses. Wire supervised IDCs as NFPA Class B or
Class A circuits. The modules come with a thermoplastic cover for mounting
to a 4-inch (10.16 cm) square mounting box.
FMM-101 FMM-101A Functionally similar to the FMM-1 Monitor Module, but offered in a smaller
package for mounting directly in the electrical box of the device being
monitored. (Class B input circuit only.)
Pull Stations
NBG-12LX NBG-12LX An addressable manual pull station with key-lock reset feature. The
addressable module is housed within the pull station.
N/A N-MPS Series Addressable Addressable manual pull stations with hex-key reset feature. The
addressable module is housed within the pull station.N-MPS-SA/N-MPS-
SAC are single-stage; N-MPS-2A/N-MPS-2AC are dual stage. All models
include screw terminal connectors and a hex key reset. Two-stage manual
stations include a keyswitch and one key. N-MPS-SAC and N-MPS-2AC
include N/C ancillary contact.
Control Modules
FCM-1 FCM-1A Control Module, NAC: Addressable Control Module used as Notification
Appliance Circuits (NACs) to power and supervise compatible, UL-listed
notification appliances. Wired supervised NACs as NFPA Class B or Class
A. The modules come with a thermoplastic cover for mounting to a 4-inch
(10.16 cm) square mounting box.
FCM-1-REL FCM-1-RELA Control Module for releasing applications. FlashScan only.
(For use with NFS2-3030, NFS2-640, NFS-320(C), and NFS-320SYS.)
UL-listed SLC Device ULC-listed SLC Device Description
