6820 / 6820EVS Manual P/N LS10144-001SK-E:C 09/28/2017 9
• Single enclosure for both Fire and Emergency Control System components.
• Support for one EVS-VCM.
1.2 About this Manual
This manual is intended to be a complete reference for all installation and operation tasks for the 6820* and 6820EVS**. Please let us
know if the manual does not meet your needs in any way. We value your feedback!
* All references to 6820 within this manual are applicable to the 6820EVS.
** Further installation instructions for the 6820/EVS and accessories can be found in the EVS Series installation manual P/N LS10062-
001-SK-E.
1.2.1 Terms Used in this Manual
The following terminology is used with the above mentioned control panels:
1.3 Compatible Products
Table 1.1 lists the products available from Honeywell Silent Knight for use with the 6820 and 6820EVS.
Term Description
SLC Signaling line circuit
Module The term module is used for all hardware devices except for SLC addressable devices and
notification appliances. This includes the 6820 or 6820EVS panel itself and the built-in power
supply. It also refers to any (optional) 5815XL or 6815 SLC expansion modules.
Input Point An addressable sensing device, such as a smoke or heat detector or a contact monitor device.
Input Zone A protected area made up of input points.
Output Point
(or “Output Circuit”)
A notification point or circuit for notification appliances. Relay circuits and auxiliary power
circuits are also considered output points.
Output Group (OPG) A group of output points. Operating characteristics are common to all output points in the
group.
Output (or “Cadence”) Pattern The pattern that the output will use, for example, Constant, March Code, ANSI 3.41. Applies to
zones and special system events. See “Cadence Patterns” on page 198 for additional
information.
Mapping Mapping is the process of specifying which outputs are activated when certain events occur in
the system. Section “Mapping Overview” on page 97 explains mapping in detail.
EVS Emergency Voice System.
Common Communication Link Up to 17 panels can be linked. Consist of any combination of 17 panels of these model
numbers:6700, 6808, 6820, or 6820EVS. For reporting purposes only. Not a peer-to-peer
networked system.
SWIFT Smart Wireless Integrated Fire Technology
Type of Device Model Description
SK Addressable
SLC Devices
See Section 7.1 for a list of compatible devices.
SD Addressable
SLC Devices
See Section 7.2 for a list of compatible devices.
SWIFT Wireless
SLC Devices
See Section 7.3 for a list of compatible devices
Table 1.1 6820 or 6820EVS Compatible Products
