22 6820 / 6820EVS Manual P/N LS10144-001SK-E:C 09/28/2017
3.7.2 Current Draw Worksheet for SK SLC Devices
Use Table 3.2 to determine current requirements during alarm/battery standby operation SK SLC devices are installed. The 6820EVS
FACP supports up to a total of 1110 SLC devices, consisting of any combination of Sensors and Modules.
6
Device # of Devices Current per Device
Standby
Current
Alarm
Current
For each device use this formula: This column X This column = Current per number of devices.
Fire Panel (battery current draw)
1 Standby: 190 mA 190 mA
Alarm: 250 mA 250 mA
Addressable SLC Detectors
SK-PHOTO Standby/Alarm: .30 mA
1
mA mA
SK-PHOTO-T mA mA
SK-HEAT mA mA
SK-HEAT-HT mA mA
SK-ACCLIMATE mA mA
SK-HEAT-ROR mA mA
SK-DUCT
2
(includes PhotoR) mA mA
SK-PHOTO-W
SLC Standby: 200µA mA
Alarm: 4.5mA mA
SK-PHOTO-R-W
SLC Standby: 200µA mA
Alarm: 4.5mA mA
SK-PHOTO-T-W
SLC Standby: 200µA mA
Alarm: 4.5mA mA
SK-HEAT-W
SLC Standby: 200µA mA
Alarm: 4.5mA mA
SK-HEAT-ROR-W
SLC Standby: 200µA mA
Alarm: 4.5mA mA
SK-HEAT-HT-W
SLC Standby: 200µA mA
Alarm: 4.5mA mA
SK-BEAM (without integral test)
SLC Standby/Alarm: 2 mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-BEAM-T
3
(with integral test)
SLC Standby/Alarm: 2 mA mA mA
Aux. Pwr Standby: 2 mA mA
Alarm: 8.5 mA mA
SK-FIRE-CO
SLC Standby: .30 mA mA
Alarm: 7.2 mA mA
Addressable SLC Module
SK-MONITOR Standby/Alarm: .375 mA mA mA
SK-MINIMON mA mA
SK-PULL-SA mA mA
SK-PULL-DA mA mA
SK-MONITOR-2 Standby/Alarm: .75 mA mA mA
SK-MONITOR-10 Standby/Alarm: 3.5 mA mA mA
SK-CONTROL
SLC Standby: .375 mA mA
Alarm: .375 mA mA
Aux Pwr Standby: 1.7 mA mA
Alarm: 7 mA mA
SK-CONTROL-6
SLC Standby: 2.25 mA mA
Alarm: 2.25 mA mA
Aux Pwr Standby: 8 mA mA
Alarm: 20 mA mA
SK-RELAY Standby/Alarm: .255 mA mA mA
SK-RELAY-6 Standby/Alarm: 1.45 mA mA mA
SK-RELAYMON-2
Standby: 1.3 mA mA
Alarm: 24 mA mA
Table 3.2 Current Draw Worksheet for SK SLC Devices
