Honeywell Voyager 1472g User Manual

88 Voyager XP User Guide
User-Specified Aimer Delay
If you want to set your own length for the duration of the delay, scan the barcode
below, then set the time-out by scanning digits (0 - 4,000 ms) from the
Programming Chart, then scan Save.
Aimer Mode
This feature allows you to turn the aimer so that it is always on, always off, or in
pulse mode. Pulse mode provides the best scan performance. Always On mode
turns the aimer On while taking a picture. Pulse Mode turns the aimer Off while
taking a picture and pulses the aimer when not taking a picture.
Default = Pulse Mode.
Centering
Use Centering to narrow the scanner’s field of view to make sure that when the
scanner is hand-held, it reads only those barcodes intended by the user. For
instance, if multiple codes are placed closely together, centering will insure that
only the desired codes are read.
Note: To adjust centering when the scanner is in the stand, see Presentation
Centering (page 4-80).
* Off (no delay)
Delay Duration
Always Off
Always On
*Pulse Mode

Honeywell Voyager 1472g Specifications

General

Environmental Sealing	IP42
Expected Duration of Operation	14 hours
Expected Charge Time	4.5 hours
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
IP Rating	IP42
Weight	210 g (7.4 oz)
Connectivity	Bluetooth, USB
Scan Pattern	Area Image
Decode Capability	1D
Battery	2400 mAh Li-ion
Drop Specification	1.5 m (5 ft) to concrete
Number of Scans	50, 000 scans per charge
Interface	USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Humidity	5% to 95% relative humidity, non-condensing
Dimensions	173 mm x 62 mm x 82 mm (6.8 in x 2.4 in x 3.2 in)
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC
Scan Technology	Area Imaging
