Honeywell Voyager 1472g User Manual

Voyager XP User Guide 215
Postal Symbologies
Chinese Sensible Code (Han Xin Code) ]X0 H 48
Codablock A ]O6 0, 1, 4, 5, 6 V 56
Codablock F ]Om 0, 1, 4, 5, 6 q 71
Code 49 ]Tm 0, 1, 2, 4 l 6C
Data Matrix ]dm 0-6 w 77
GS1 ]em 0-3 y 79
GS1 Composite
]em 0-3 y 79
GS1 DataBar Omnidirectional
]em 0-3 y 79
MaxiCode ]Um 0-3 x 78
PDF417 ]Lm 0-2 r 72
MicroPDF417
]Lm 0-5 R 52
QR Code ]Qm 0-6 s 73
Micro QR Code
]Qm s73
AIM Honeywell
Symbology ID
Possible modifiers
(m)
ID Hex
AIM Honeywell
Symbology ID
Possible modifiers
(m)
ID Hex
All Symbologies 99
Australian Post ]X0 A 41
British Post ]X0 B 42
Canadian Post ]X0 C 43
China Post ]X0 Q 51
InfoMail ]X0 , 2c
Intelligent Mail Barcode ]X0 M 4D
Japanese Post ]X0 J 4A
KIX (Netherlands) Post ]X0 K 4B
Korea Post ]X0 ? 3F
Planet Code ]X0 L 4C
Postal-4i ]X0 N 4E
Postnet ]X0 P 50

Honeywell Voyager 1472g Specifications

General

Environmental Sealing	IP42
Expected Duration of Operation	14 hours
Expected Charge Time	4.5 hours
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
IP Rating	IP42
Weight	210 g (7.4 oz)
Connectivity	Bluetooth, USB
Scan Pattern	Area Image
Decode Capability	1D
Battery	2400 mAh Li-ion
Drop Specification	1.5 m (5 ft) to concrete
Number of Scans	50, 000 scans per charge
Interface	USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Humidity	5% to 95% relative humidity, non-condensing
Dimensions	173 mm x 62 mm x 82 mm (6.8 in x 2.4 in x 3.2 in)
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC
Scan Technology	Area Imaging
