Voyager XP User Guide 81
Scan Presentation Centering On, then scan one of the following barcodes to
change the top, bottom, left, or right of the centering window. Then scan the per-
cent you want to shift the centering window using digits on the Programming
Chart. Scan Save. Default Presentation Centering = 40% for Top and Left, 60% for
Bottom and Right.
In-Stand Sensor Mode
This feature senses when the scanner is removed from the stand and tells it to
begin manual triggering. When Sensor On is enabled, the scanner defaults to Pre-
sentation Mode when it is in the stand, and to Manual Trigger Mode when it is
removed from the stand. Default = Sensor On.
Presentation Centering On
* Presentation Centering Off
Top of Presentation
Centering Window
Bottom of Presentation
Centering Window
Left of
Presentation Centering
Window
Right of Presentation
Centering Window
* Sensor On
Sensor Off

Honeywell Voyager 1472g Specifications

General

Environmental Sealing	IP42
Expected Duration of Operation	14 hours
Expected Charge Time	4.5 hours
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
IP Rating	IP42
Weight	210 g (7.4 oz)
Connectivity	Bluetooth, USB
Scan Pattern	Area Image
Decode Capability	1D
Battery	2400 mAh Li-ion
Drop Specification	1.5 m (5 ft) to concrete
Number of Scans	50, 000 scans per charge
Interface	USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Humidity	5% to 95% relative humidity, non-condensing
Dimensions	173 mm x 62 mm x 82 mm (6.8 in x 2.4 in x 3.2 in)
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC
Scan Technology	Area Imaging
