38 Voyager XP User Guide
If the scanner and base have previously been linked, you do not receive any feed-
back. If this is the first time that the scanner and base are linked, both devices emit
a short chirp when their radios link. At this point, that one scanner is linked to one
base.
To determine if your cordless system is set up correctly, scan one of the sample
barcodes in the back of this manual. If the scanner provides a single good read
beep and the green LED lights, the scanner has successfully linked to the base. If
you receive an error tone and the red LED lights, the scanner has not linked to the
base. Refer to page 211 for troubleshooting information.
Link the Scanner to an Access Point
Turn on the computer (laptop/desktop). Plug the interface
cable into the Access Point first and then into the appropri-
ate port on the computer. The Page button lights up when
the connection to the host is made.
Scan the linking barcode on the top of the Access
Point to establish a connection between the
Access Point and the scanner. The scanner emits a
short beep and flashes the green LED to confirm a
connection with the Access Point. The Access
Point’s Page button remains blue.
CCB01-010BT-V1N Charge Base
Page
Button

Honeywell Voyager 1472g Specifications

General

Environmental Sealing	IP42
Expected Duration of Operation	14 hours
Expected Charge Time	4.5 hours
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
IP Rating	IP42
Weight	210 g (7.4 oz)
Connectivity	Bluetooth, USB
Scan Pattern	Area Image
Decode Capability	1D
Battery	2400 mAh Li-ion
Drop Specification	1.5 m (5 ft) to concrete
Number of Scans	50, 000 scans per charge
Interface	USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Humidity	5% to 95% relative humidity, non-condensing
Dimensions	173 mm x 62 mm x 82 mm (6.8 in x 2.4 in x 3.2 in)
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC
Scan Technology	Area Imaging
