Honeywell Voyager 1472g User Manual

198 Voyager XP User Guide
Voyager XP 1472g Cordless Scanner Product
Specifications
Image Size 1040 x 720 pixels
Scan Performance
Pitch, Skew ± 65°, ± 70°
Motion Tolerance:
Presentation Mode up to 70cm per second for 13 mil UPC
Print Contrast 20%
Parameter Specification
Parameter Specification
Mechanical
Height 6.8 in. (17.3cm)
Length 3.2 in. (8.2cm)
Width 2.5 in. (6.2cm)
Weight 7.3 oz. (210g)
Electrical
Battery:
Lithium Ion 2400 mAH lithium-ion
Number of Scans Up to 50,000 per charge
Expected Hours of Operation 14
Expected Charge Time 4.5 hours
Illumination White color (CCT 2700K)
Aiming Red color, 624nm peak wavelength
Radio
Frequency 2.4 to 2.5 GHz (ISM Band) Frequency Hopping Bluetooth
v.4.2
Range 330 ft. (100 m) typical
Data Rate Up to 1 MBps
Environmental
Operating Temperature 32° F to 122° F (0° C to 50° C)
Storage Temperature (with battery) -4°F to 95°F (-20°C to 35°C) storage for 90 days
-4°F to 68°F (-20°C to 20°C) storage for 1 year
Storage Temperature (without
battery)
-40° F to 140° F (-40° C to 60° C)
Humidity Up to 95% non-condensing
Drop Operational after 30 drops to concrete from 5.9 ft. (1.8 m)
Environmental Sealing IP52

Honeywell Voyager 1472g Specifications

General

Environmental Sealing	IP42
Expected Duration of Operation	14 hours
Expected Charge Time	4.5 hours
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
IP Rating	IP42
Weight	210 g (7.4 oz)
Connectivity	Bluetooth, USB
Scan Pattern	Area Image
Decode Capability	1D
Battery	2400 mAh Li-ion
Drop Specification	1.5 m (5 ft) to concrete
Number of Scans	50, 000 scans per charge
Interface	USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Humidity	5% to 95% relative humidity, non-condensing
Dimensions	173 mm x 62 mm x 82 mm (6.8 in x 2.4 in x 3.2 in)
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC
Scan Technology	Area Imaging
