Honeywell Vuquest 3310g User Manual

7 - 21
that supports concatenation of neighboring symbols, and 4) the standard
layout for bar codes on a blood product label. Use the bar codes below to
turn concatenation on or off. Default =Off.
Code 128 Message Length
Scan the bar codes below to change the message length. Refer to
Message Length Description (page 7-2) for additional information. Mini-
mum and Maximum lengths = 0-80. Minimum Default = 0, Maximum
Default = 80.
Code 128 Append
This function allows the scanner to append the data from several Code 128
bar codes together before transmitting them to the host computer. When
the scanner encounters a Code 128 bar code with the append trigger char-
acter(s), it buffers Code 128 bar codes until it reads a Code 128 bar code
that does not have the append trigger. The data is then transmitted in the
order in which the bar codes were read (FIFO). Default = On.
* Off
On
Minimum Message Length
Maximum Message Length
Off
* On

Honeywell Vuquest 3310g Specifications

General

Type	Fixed bar code reader
Sensor type	-
Yaw reading angle	-65 - 65 °
Pitch reading angle	-45 - 45 °
Optical sensor resolution	838 pixels
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	PS/2
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Power source type	AC
Power consumption (standby)	0.45 W
Power consumption (typical)	2.3 W
Product color	White
International Protection (IP) code	IP53
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Cables included	USB

Weight and Dimensions

Depth	74 mm
Width	50 mm
Height	26 mm
Weight	75 g
