Hitching to a Cat. V adjustable drawbar.
The return ow pressure at the fan drive
must not exceed 5 bar, as otherwise the
hydraulic motor may be destroyed.
Hook the scales here for calibration.
Adjust the coulter pressure -
follow the operating instructions
Stickers
Loading hook;
hook the sling gear (chains, ropes etc.) into
this loading hook during loading.
alle Verladehacken ed Sept 03
DatumEnt w.DateinameZeichnungsnummerMaschine Zeichnung
00380880
00380880
Retighten the wheel nuts / wheel bolts
after 50 km or 10 hours.
Retighten every day - see maintenance
overview.
alle Aufkleber ed 113700340358
Ent w.DateinameMaschine Zeichnung JJKWZeichnungsnummer
00380359
Tighten with the appropriate torque.
Open and close the lock valve for the draw-
bar cylinder.
