Maestro preparation kit
All Focus with three-point hitching at the rear
end can be used with a Maestro RC seedbar
for single grain drilling.
In order to be able to check coulter pressure and
vacuum, the front of the hoppers are equipped
with two further pressure gauges.
B
A
Maestro preparation kit - pressure gauges
A Vacuum
B Coulter pressure
In order to hitch a Maestro RC to a Focus
with three-point hitching one must strictly
follow the operating instructions of the
Maestro RC.
Border discs
The border discs prevent the formation of banks
when driving adjoining passes. They must be
adjusted after the tines. The accompanying
package contains a suitable key.
Border discs
E
Border disc adjustment
¾ Remove screw (E) for this purpose.
¾ The holding plate has several bore holes.
¾ Swing the arm of the border disc to the desired
position and secure it again with the screw (E).
Maintenance
¾ Check the bearing play at regular intervals
and replace the bearing, if necessary.
¾ Free the bearing of wound up obstructions.
61
