Disc harrow eld
As a measure to extend the range of applica-
tions, the Focus TD can be equipped with a disc
harrow system, instead of the tine eld.
This makes the Focus TD suitable for use under
damp conditions, when seed bed preparation
with tines is no longer satisfactory.
With the disc system no fertiliser can be placed.
The twin hopper is in this case used just as a
seed-seed hopper.
Focus TD with disc harrow eld
Installing the disc harrow eld
WARNING
Dropping / lowering machine parts
can cause severe crushing etc.!
¾ Support a lifted machine with appropriate
means.
¾ Do not work under a properly secured ma-
chine.
¾ Instruct persons to leave the danger zone.
¾ Comply with the accident prevention instruc-
tions.
CAUTION
Danger of injury when working with the machine.
¾ Always wear adequate protective equipment
for all repair and maintenance work.
WARNING
Danger of injury caused by the machine lowering.
¾ Always support the machine with suitable
means before starting any assembly or main-
tenance work on tines and coulters.
¾ Secure the lift cylinders with aluminium clips.
¾ Hitch the machine up to the tractor and park
it on rm, level ground.
¾ Loosen the pneumatic hoses from the tines
and remove these from the working area.
¾ Disconnect the hydraulic connections be-
tween core machine and tine eld.
WARNING
Leaking out hydraulic uid can cause serious
injuries!
Danger of injuring by unwanted machine move-
ments.
¾ Connect or disconnect the hydraulic lines only
when the hydraulics have been de-pressur-
ized on both machine and equipment sides.
¾ In the event of injury, consult a doctor im-
mediately.
62
