horsch FOCUS ST - Lubrication Points - Focus TD

Lubrication points (Lubrication grease: DIN 51825 KP/2K-40) - Number of lubrication points in brackets
Bolt parallelogram - rear (A) lubricate (2) 40 h / after pressure cleaning
Spindles for coulter pressure adjustment (B) lubricate (1) 40 h / after pressure cleaning
Bout markers (C) lubricate (2) 40 h / after pressure cleaning
Swinging drawbar hitching - pivot bolt (D) lubricate (2) 40 h / after pressure cleaning
Two-point hitching - rotation and hinged bearing (E) lubricate (2) 40 h / after pressure cleaning
Ball head hitching (F) lubricate ball head (1) 40 h / after pressure cleaning
Bolt for parallelogram - front (G) lubricate (4) 40 h / after pressure cleaning
Lubrication points - Focus TD
Lubrication points with the addition “2x” are
located on both sides of the machine.
* Quantity depending on working width
2x
A
2x*
B
2x
C
2x
D
E
F
2x
G
76
