1.
2.
3.
¾ Tighten the screw connections for mounting
the wings on the nut. Do not tighten on the
screw head.
¾ Tighten all screw connections with a nutrunner
or torque spanner.
¾ Observe the tightening torque: 160 ± 10 Nm
Coulter
The Focus TD uses LD coulters. With a working
width of 40 mm they enable deep work without
bringing coarse clots to the surface, e.g. under
moist conditions.
For especially wear intensive soils e have the
coulter LD Plus available. It is carbide coated.
Coulter LD Plus
Changing the coulter
The following must be observed when replac-
ing components of the MulchMix, LD and ULD
coulter (coulter tips, guide plates, wings):
¾ Use only original HORSCH wear items.
¾ Use new screws and nuts with each replace-
ment.
¾ Check for correct seating of the four-cornered
shaft coulter screws in the coulter tips and
guide plates:
¾ Observe the sequence when tightening
MulchMix coulter tips together with guide
plates:
36
