Light kit 80
WARNING: To reduce the risk of personal injury, fire, or damage to the equipment, do not
exceed the recommended voltage for the rack.
HP 110V/220V light kit specifications
Parameter Value
Height
116 mm
Depth
50 mm
Width
452 mm
Weight
approximately 1 kg
Rated input
100–240 V, 50/60 Hz
Maximum rated output
10 A/250 VAC
Illuminant
F14W/133-T8, Coolwhite
Protection class
1
Degree of protection
IP20 (IEC 529/EN 60 529)
Power consumption
approximately 27 VA
Current consumption
0, 08 A at 240 V
0, 012 A at 230 V
0, 175 A at 100 V
Operating temperature
-25°C to 50°C
Type of start
Candle power
700 lm
Illumination
approximately 90 1X (measured by 1
m distance)
Test standard
UL153, (Portable Lamps), File
E243499 ENEC/GS according
EN60598-1 (at test)
EMC
EN61547, EN55015, EN61000-6-3,
EN61000-6-2, EN61000-3-3
