About this device
The HP Rear Extension kit enables you to add 200-mm (7.87-in) of depth to the rear of the HP 10000 Series
and HP 10000 G2 Series racks.
The HP Rear Extension kit only fits the 600-mm (23.62-inch) wide (42U and 47U) rack models.
Kit contents
Item Quantity
Rear extension assembly
•
Left side assembly
•
Right side assembly
•
Top assembly
•
Bottom assembly
1
M5.5 self tapping screw
8
M6 machine screw
8
Rear extension cord
3
Cable management bracket
6
This kit might contain extra hardware for your convenience.
Required tools
The following tools are required for installation:
• T-25 Torx driver
• T-30 Torx driver
Removing the rear doors
1. Open the hinge brackets by pulling up the top hinge pin and pulling down the bottom hinge pin (1).
