77
Product
Code
Description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz*km)
Maximum
transmission
distance
JD109A
HP X170 1G SFP LC
LH70 1550
Transceiver
1550 9/125 N/A 70 km (43.50 miles)
JD110A
HP X170 1G SFP LC
LH70 1570
Transceiver
1570 9/125 N/A 70 km (43.50 miles)
JD111A
HP X170 1G SFP LC
LH70 1590
Transceiver
1590 9/125 N/A 70 km (43.50 miles)
JD112A
HP X170 1G SFP LC
LH70 1610
Transceiver
1610 9/125 N/A 70 km (43.50 miles)
IMPORTANT:
• You must use the HP X120 1G SFP LC BX 10-U Transceiver (JD098B) and the HP X120 1G SFP LC BX
10-D Transceiver (JD099B) in pairs.
• The 100/1000-Mbps SFP port of a combo interface does not support transceiver module JD089B.
Table 32 100-Mbps SFP module specifications
Product
code
Description
Central wavelength
(nm)
Fiber
diameter (μm)
Maximum
transmission
distance
JD102B
HP X115 100M SFP LC FX
Transceiver
1310
50/125
2 km (1.24
miles)
62.5/125
JD120B
HP X110 100M SFP LC LX
Transceiver
1310 9/125
15 km (9.32
miles)
JD090A
HP X110 100M SFP LC LH40
Transceiver
1310 9/125
40 km (24.86
miles)
JD091A
HP X110 100M SFP LC LH80
Transceiver
1550 9/125
80 km (49.71
miles)
JD100A
HP X110 100M SFP LC BX 10-U
Transceiver
TX: 1310
RX: 1550
9/125
15 km (9.32
miles)
JD101A
HP X110 100M SFP LC BX 10-D
Transceiver
TX: 1550
RX: 1310
9/125
15 km (9.32
miles)
IMPORTANT:
You must use the HP X115 100M SFP LC BX 10-U Transceiver (JD100A) and the HP X115 100M SFP LC
BX 10-D Transceiver (JD101A) in pairs.
