115
If you configure both static and dynamic MAC-based VLAN assignment on the same port, dynamic MAC-
based VLAN assignment applies, and the port drops the frames that do not exactly match any MAC
address-to-VLAN entry.
Approach 3: Dynamic MAC-based VLAN
Use dynamic MAC-based VLAN with access authentication (such as 802.1X authentication based on
MAC addresses) to implement secure, flexible terminal access. After configuring dynamic MAC-based
VLAN on the switch, you must configure the MAC address-to-VLAN entries on the access authentication
server.
When a user passes authentication of the access authentication server, the switch obtains VLAN
information from the server, generates a MAC address-to-VLAN entry by using the source MAC address
of the user packet and the VLAN information, and assigns the port to the MAC-based VLAN. When the
user goes offline, the switch automatically deletes the MAC address-to-VLAN entry, and removes the port
from the MAC-based VLAN.
Configuring MAC-based VLAN
MAC-based VLANs are available only on hybrid ports.
The MAC-based VLAN feature is mainly configured on the downlink ports of the user access devices. Do
not enable this function together with link aggregation.
Configuring static MAC-based VLAN assignment
To configure static MAC-based VLAN assignment
To do... Use the command... Remarks
1. Enter system view
system-view —
2. Associate MAC addresses
with a VLAN
mac-vlan mac-address mac-address
[ mask mac-mask ] vlan vlan-id
[ priority priority ]
Required.
Enter Ethernet
interface view
interface interface-type interface-
number
3. Enter
Ethernet
interface
view or
port
group
view
Enter port
group view
port-group manual port-group-name
Use either command.
• The configuration made in
Ethernet interface view applies
only to the current port.
• The configuration made in port
group view applies to all ports in
the port group.
4. Configure the link type of
the ports as hybrid
port link-type hybrid Required.
5. Configure the hybrid ports
to permit packets of
specific MAC-based
VLANs to pass through
port hybrid vlan vlan-id-list { tagged
| untagged }
Required.
By default, a hybrid port only
permits the packets of VLAN 1 to
pass through.
6. Enable MAC-based VLAN
mac-vlan enable
Required.
Disabled by default
7. Configure VLAN matching
precedence
vlan precedence { mac-vlan | ip-
subnet-vlan }
Optional.
By default, VLANs are preferentially
matched based on MAC addresses.
