18
To do… Use the command… Remarks
2. Enter Ethernet interface view
interface interface-type interface-
number
—
3. Set the MDI mode of the
Ethernet interface
mdi { across | auto | normal }
Optional.
By default, a copper Ethernet
interface operates in auto mode to
negotiate pin roles with its peer.
Enabling bridging on an Ethernet interface
When an incoming packet arrives, the switch looks up the destination MAC address of the packet in the
MAC address table. If an entry is found, but the outgoing interface is the same as the receiving interface
(for example, if the destination and source MAC addresses of the packet are the same), the switch
discards the packet.
To enable the switch to return such packets to the sender through the receiving interface rather than drop
them, enable the bridging function on the Ethernet interface.
To enable bridging on an Ethernet interface:
To do… Use the command… Remarks
1. Enter system view
system-view —
2. Enter Ethernet interface view
interface interface-type interface-
number
—
3. Enable bridging on the
Ethernet interface
port bridge enable
Required
Disabled by default
Testing the cable connection of an Ethernet interface
Optical interfaces do not support this feature.
If the link of an Ethernet interface is up, testing its cable connection will cause the link to come down and
then go up.
Test the cable connection of an Ethernet interface for a short or open circuit. The device displays cable
test results within five seconds. If any fault is detected, the test results include the length of the faulty cable
segment.
To test the cable connection of an Ethernet interface:
To do… Use the command… Remarks
1. Enter system view
system-view —
2. Enter Ethernet interface view
interface interface-type interface-
number
—
3. Test the cable connected to
the Ethernet interface
virtual-cable-test Required
