5
The value returned is applies
only to the attenuation mode (see
\[:SOURce]:POWer:ATTenuation:AUTO?").
If you specify MIN , DEF ,or MAX with the query,
it will return, respectively, the minimum,
default, or maximum amplitude level.
Example OUTPUT 724;":POW:ATT:AUTO OFF"
OUTPUT 724;":POW 200UW OUTPUT
724;":POW:ATT 22.32DB"
OUTPUT 724;":POW:ATT?" ENTER 724;A$
[:SOURce]:POWer:ATTenuation:AUTO
Attenuator
Syntax [ :SOURce ] :POWer:ATTenuation:AUTO < wsp >
OFF j ON j 0 j 1
Description This command selects Power or Attenuation
Mode.InPower Mode, you specify the output
power. In Attenuation Mode, you must
specify both the laser output power, and the
attenuation level.
Use ON or 1 to select Power Mode.
Use OFF or 0 to select Attenuation Mode
[:SOURce]:POWer:ATTenuation:AUTO?
Attenuator
Syntax [ :SOURce ] :POWer:ATTenuation:AUTO?
Description This query returns whether the instrument is in
Power Mode, or Attenuation Mode.
1 indicates Power Mode.
0 indicates Attenuation Mode
Remote Commands 5-23
