Chapter 6, Call Processing Subsystem
CALL CONFIGURE Screen
NOTE: In order to ensure that the Test Set makes the correct decisions regarding the presence of the
mobile stations’s RF carrier, the Test Set’s RF power meter should be zeroed before using the
Call Processing Subsystem. Failure to zero the power meter can result in erroneous RF power
measurements. See "Conditioning the Test Set for Call Processing" on page 130 for
information on zeroing the RF Power meter manually.
CMAX
The CMAX field sets the number of access channels in the system. This will
determine how many channels must be scanned by the mobile station when trying
to access the Test Set. The value of this field will affect the time required for the
mobile station to connect with the Test Set.
Detector
This field is used to select the type of detector used to measure the amplitude of
the audio signal being measured. Refer to the Detector field description, on page
101
for descriptions of the detectors available.
TX Pwr Zero
The TX Pwr Zero function establishes a 0.0000 W reference for measuring RF
power at the RF IN/OUT port. See "TX Pwr Zero" on page 427 for further
information.
CAUTION: RF power must not be applied while zeroing. Set the RF GENERATOR screen’s Amplitude
field to off to prevent internal cross-coupling into the power detector while zeroing.
