HP 8921A - Setting Markers on the Spectrum Analyzer; Spectrum Analyzer Marker Menu Fields

459
Chapter 21, Spectrum Analyzer Screen
Field Descriptions
Spectrum Analyzer Marker Menu Fields
Figure 101 Setting Markers on the Spectrum Analyzer
Marker To:
• Peak moves the marker to the highest peak and enters the location in the Position
field.
• Next Peak moves the marker to the next peak to the right and enters the location in
the Position field.
• Center Freq changes the center frequency value to match the current position of the
marker.
• Ref Level changes the reference level setting to match the current position of the
marker.
Position
This field sets the marker position, referenced to the left side of the screen.
