552

Error Messages

Negative Numbered Error Messages

Negative numbers preceding the error messages text correspond to the error conditions

outlined in the Standard Commands for Programmable Instruments (SCPI). For more

information on SCPI, order the following book,

A Beginner’s Guide to SCPI Addison-Wesley Publishing Company ISBN 0-201-56350-9

HP P/N 5010-7166

or contact,

Fred Bode, Executive Director SCPI Consortium

8380 Hercules Drive, Suite P3

La Mesa, CA 91942

Phone: (619) 697-8790, FAX: (619) 697-5955 CompuServe Number: 76516,254

Negative numbered error messages take the form: ERROR −XX <error message>

For example:

Error -128 Numeric data not allowed

Error -141 Invalid character data
