Chapter 7, Configure Screen
Field Descriptions
RF Chan Std
Use the RF channel standard field to select the channel standard for the radio-
under-test. The RF Generator’s and the RF Analyzer’s frequencies are
automatically set to correspond to the channel number entered in the RF Channel
field. RF Channel replaces the Amplitude and Tune Freq fields on several
screens when channel tuning is used.
Each standard has a prefix code that indicates what type of radio to test; mobile
station (MS) or land station (LS). For example, if you are testing an AMPS
mobile, select
MS AMPS.
For the NAMPS standards, a third letter is added indicating which frequency band
is used: upper, middle, or lower. For example, when testing a mobile station using
the lower band, choose
MSL NAMPS. Testing a land station using the upper band
you would select LSU NAMPS.
The
USER-DEF selection is used to define your own channel assignments. When
selected, you enter the
Base Freq, Chan Space, and (Gen)-(Anl) settings.
See Also
Base Freq (User Defined)
field description, on page 203
Chan Space (User Defined)
field description, on page 204
(Gen)-(Anl)
field description, on page 206
