413
Chapter 16, Radio Interface Screen
Using the Radio Interface (Manual Operation)
Figure 90
The I/O Config field will also output data to the output data line comparators.
The I/O Config field, however, is primarily intended to configure parallel data
lines as inputs or outputs. See the Input Data field description, on page 406.
+
-
Parallel Data
Strobe
Logic Voltage
LM 339M
Parallel Data Strobe
+
-
Output Data
Fixed Ref-
erence
Logic Voltage
LM 339M
Output Data Line
Data Output
(1 of 16)
1
0
Strobe POL
High/Low
External device should latch data on
Strobe POL Level
to allow Output Data
time to settle.
Pin 13
Pins 9 - 34
5 µ S
