425
Chapter 17, RF Analyzer Screen
Field Descriptions
Tune Freq
RF Analyzer tune frequency sets the center frequency for the RF signal to be
analyzed.
See Also
Tune Mode
field description (this page)
Tune Mode
This field selects automatic or manual tuning of the RF Analyzer.
Auto causes the RF Analyzer to find the signal with the greatest amplitude
>-36 dBm, and set the tune frequency for that signal.
Manual requires the operator to set the tune frequency for the RF signal to be
analyzed.
Operating Considerations
Changing the Tune Mode also changes the RF frequency display. Automatic
tuning enables the TX Frequency measurement. Manual tuning enables the TX
Freq Error
measurement.
After autotuning to the desired signal, select
Manual to prevent the Tune Freq
from changing when the signal is no longer applied.
TX Freq Error/TX Frequency
This measurement area is used to display transmitter frequency error or
transmitter frequency.
See Also
Tune Mode
field description (this page)
