Chapter 18, RF Generator Screen
Field Descriptions
TX Freq Error
TX Frequency
This measurement displays transmitter frequency error or absolute transmitter
frequency.
See Also
Tune Mode
field description, on page 297
"Displaying Measurements" on page 57
TX Power
Transmitter power measures RF power at the RF IN/OUT port.
Operating Considerations
Maximum signal levels at each port are printed on the front panel.
Only the RF IN/OUT port can be used for measuring TX power on this screen.
When the
Input Port
1
is set to Ant, four dashes (- - - -) appear in place of digits
for this measurement.
Use the Spectrum Analyzer to measure low-level RF power (
≤200 mW) at the
ANT IN port.
1. The Input Port field is accessed on the TX TEST, DUPLEX TEST, and
RF ANALYZER screens.
CAUTION: Connecting a signal of >200 mW to the ANT IN port can cause instrument damage (although
internal protection circuits can typically withstand a short-duration signal of 1 or 2 Watts).
If the overpower circuit is triggered (signified by a warning message at the top of
the screen), remove the signal from the ANT IN port, and press
the MEAS RESET key or turn the Test Set off and on reset it.
See Also
TX Power
field description, on page 426
TX Pwr Zero
field description, on page 427
