489

Chapter 22, Tests Screen

TESTS (Printer Setup)

Printer Address:

This field is used to specify the address of an HP-IB printer. This field is only

displayed if the Printer Port: field is set to HP-IB.

Printer Port:

This field is used to select the port your printer is connected to.

Run Test

Selecting this field loads and runs the test chosen in the Select Procedure

Filename:

field on the TESTS (Main Menu) screen.
