595

Chapter 25, Modifications, Accessories, Manuals, Support

Accessories

Plug Type

Plug Descriptions

male/female

HP Part #

(cable &plug)

Cable Descriptions

Straight/Straight 8120-0698 90 inches, black

Used in the following locations

Peru

Plug Type

Plug Descriptions

male/female

HP Part #

(cable &plug)

Cable Descriptions

Straight/Straight

Straight/90°

8120-2104

8120-2296

79 inches, gray

Used in the following locations

Switzerland
