82
Chapter 3, Operating Overview
Using Remote Control
Table 5 Equivalent Front-Panel Control Characters
Function
Equivalent
ESC
Character
Function
Equivalent
ESC
Character
CANCEL ! A X
PERCENT MHZ_V ( EEX Z
S_KHZ_MV ) YES_ON_OFF [
BACKSPACE - NO_PPM_W ]
ENTER . RX a
RELEASE 0 TX b
K1 1 DUPLEX c
K2 2 PREV d
K3 3 TESTS_MAIN e
K4 4 LOCAL f
K5 5 RECALL g
K1_PRIME 6 MEAS_RESET h
K2_PRIME 7 PRESET i
K3_PRIME 8 INCR_DIV_10 j
ASSIGN 9 INCR_SET k
KNOB_TURN_CCW < INCR_TIMES_10 l
KNOB_TURN_CW > DOWN m
MSSG A UP n
HELP B SEVEN o
CONFIG C EIGHT p
HOLD D NINE q
PRINT E FOUR r
ADRS F FIVE s
SAVE G SIX t
REF_SET J ONE u
METER K TWO v
AVG L THREE w
LO_LIMIT M ZERO x
HI_LIMIT N POINT y
