Front and Back Panel Descriptions
Front Panel
The 24-port hub is shown; the 12-port and 48-port hubs are essentially the same.
ThinLAN
network
port
chain ports RS-232 console port
(for distributed management)
Optional AUI port module
installed in AUI/Xcvr slot
twisted-pair ports
hub status LEDs
and reset button
twisted-pair port LEDs
cable management
guide
power connector
cover plate over
slot for HP Ethernet SNMP Module
Back Panel
redundant power
connector
Hub Reference
Hub Reference
3-2
