AUI Cable Minimum Pin-Out
Transceiver end
15-pin female
Hub end
15-pin male
Signal
2
3
4
5
6
9
10
12
13
2
3
4
5
6
9
10
12
13
Control In circuit A
Data Out circuit A
Data In circuit Shield (common drain)
Data In circuit A
Voltage Common
Control In circuit B
Data Out circuit B
Data In circuit B
Voltage Plus
For this connection, you can use:
HP 92264D (1-meter thin AUI
extension, pin 4 not connected)
HP 92254A through H (6-meter
through 48-meter thick AUI cables)
HP 92254J (5-meter thin AUI cable,
pin 4 not connected)
Some longer cables may have all 15 pins wired.
See the IEEE 802.3 standards document for
definitions of the pins not shown here.
Cables and Connectors
Cables and Connectors
A-8
