Physical
HP J2600A 12-Port Hub
HP J2601B 24-Port Hub HP J2602B 48-Port Hub
Width:
44.2 cm (17.4 in) 44.2 cm (17.4 in)
Depth:
29.8 cm (11.7 in) 29.8 cm (11.7 in)
Height:
6.6 cm (2.6 in) 11.0 cm (4.3 in)
Weight:
4.1 kg (9.0 lb) 5.0 kg (11.0 lb)
Electrical
(The HP AdvanceStack hubs automatically adjust to any voltage between 100
and 240 volts and any frequency between 50 and 60 Hz.)
ac voltage:
100-127 volts
Voltage tolerance of +/- 10%
200-240 volts
Voltage tolerance of +/- 10%
Typical current:
0.6 A (HP J2600A, J2601B)
0.8 A (HP J2602B)
0.3 A (HP J2600A, J2601B)
0.4 A (HP J2602B)
Maximum current:
1.0 A 0.6 A
Frequency range:
50/60 Hz 50/60 Hz
Environmental
Operating Non-Operating
Temperature:
0°C to 55°C
(32°F to 131°F)
-40°C to 70°C
(-40°F to 158°F)
Relative humidity:
(non-condensing)
15% to 95%
at 40°C (104°F)
15% to 90%
at 65°C (149°F)
Maximum altitude:
4.6 km (15,000 ft) 4.6 km (15,000 ft)
Connectors
The 50-pin and RJ-45 twisted-pair ports are compatible with the
IEEE 802.3 Type 10Base-T standard.
The ThinLAN port is compatible with the IEEE 802.3 Type 10Base2
standard.
The RS-232-C console port conforms to V.22 bis. (Modem use
requires HP J2603A or B Ethernet SNMP Module.)
The maximum current ratings represent the current that could be drawn with a
fully loaded expansion slot and external MAU’s.
Specifications
Specifications
B-2
