Table 1-1
Front Panel Components
Item Component Description
1
Power On/Off LED
After plugging the power cord into a grounded AC outlet and the
workstation, if the LED is:
Off
—Workstation is ready to be powered up.
Steady Amber
—Processor or memory board is not seated properly.
After pressing the power button, if the LED is:
Steady Green
—Workstation is turned on, and the processor or
memory board is seated properly.
Blinking green
—Workstation is in Standby mode.
2
Power button Turns the workstation on or off.
3
Hard drive activity LED When lit, indicates the workstation is reading or writing data to the
hard drive(s).
4
Network activity LED
When lit, indicates the workstation is receiving or sending data on
the network.
5
Bay 4 5.25-inch, half-height drive bay, CD-ROM drive or DVD-ROM drive
6
Bay 5* 5.25-inch, half-height drive bay
7
Bay 6* 5.25-inch, half-height drive bay
8
Bay 7 3.5-inch, third-height drive bay, diskette drive
9
Speaker Premier Sound with fixed equalization
* An optional Zip drive can be installed in bay 5 or 6.
