6-24
Compaq Professional Workstation SP750 Maintenance and Service Guide
Table 6-23
PowerStorm 600 AGP Graphics Controller
Resolution Maximum Colors
Maximum Refresh Rate Supported
by Drive (Hz)
1440 x 900 16.7M 85
1280 x 1024 16.7M 85
1280 x 960 16.7M 85
1152 x 864 16.7M 85
1024 x 768 16.7M 85
800 x 600 16.7M 75
640 x 480 16.7M 85
Network Controllers
Table 6-24
Ethernet Network Interface Controller (NIC)
Physical connector RJ-45
Operating environment
Temperature
Humidity
50
°
to 95
°
F10
°
to 35
°
C
10% to 90%, noncondensing
Electrical bus 32-bit PCI bus
RJ-45 Network Cable Specifications
The RJ-45 connections use an unshielded twisted pair (UTP) cable of 22-, 24-, or 26-gauge. The
cable must comply with the IEEE 802.3 10BASE-T standard. The maximum distance between
the computer and the hub is 100 meters.
