4-4
Compaq Professional Workstation SP750 Maintenance and Service Guide
Workstation Feet
NOTE:
Not all procedures in this chapter require the removal of the workstation feet. Be sure to
thoroughly read each removal and replacement procedure before attempting to access any internal
components.
To remove the workstation feet:
1. Perform the steps in the “Service Preparations” section in this chapter, then place the
workstation on its side.
CAUTION:
Before removing the side access panel, ensure that the workstation is turned off, all
cables are disconnected from the back of the workstation, and the power cord is disconnected
from the grounded AC outlet.
2. Remove the screws that secure the feet.
3. Remove the workstation feet.
Figure 4-2. Removing the workstation feet
To replace the feet, reverse the above procedure.
