4-6
Compaq Professional Workstation SP750 Maintenance and Service Guide
Front Bezel
The front bezel is mounted to the chassis with release levers that are integrated into the bezel.
To remove the front bezel:
1. Perform the steps in the “Service Preparations” section in this chapter, then place the
workstation on its side.
CAUTION:
Before removing the side access panel, ensure that the workstation is turned off, all
cables are disconnected from the back of the workstation, and the power cord is disconnected
from the grounded AC outlet.
2. Remove the side access panel.
3. Press the front bezel release latches and remove the front bezel.
Figure 4-4. Removing the front bezel
To replace the front bezel, reverse the above procedure.
